VA140188V small slewing ring bearing thin-wall slewing bearings
| Slewing bearing No. | VA140188V | |
| Weight | [kg] | 7.5 |
| Outer diameter (O.D.) | [mm] | 259.36 |
| Inner diameter (I.D.) | [mm] | 135 |
| Bore diameter of outer ring | [mm] | 189 |
| Outside diameter of inner ring | [mm] | 187 |
| Overall height | [mm] | 35 |
| External bolt circle diameter | [mm] | 222 |
| Number of bolt hles | 16 | |
| Internal bolt circle diameter | [mm] | 154 |
| Number of bolt hles | 16 | |
| Bolt hole diameter | [mm] | M10 |
| Bolt size | [mm] | M10 |
| Height of outer ring | [mm] | 30 |
| Height of inner ring | [mm] | 30 |
| Gear P.C.D. | [mm] | 248 |
| Module | [mm] | 4 |
| Number of Teeth | 62 | |
| tooth width | [mm] | 26 |
| JINB slewing bearing | SEL140188V | |
